Welcome to the TACO Developer Documentation!

This is the developer documentation for the Threshold Automata for COnsensus Model Checker (TACO), targeted towards users that want to modify TACO or implement their own algorithms in TACO. It consists of two main sections:

Crates gives a high-level overview of the crates of TACO, and
Development Setup contains setup instructions for a development environment for working on the TACO source code

Crates¶

This section describes the high-level function of the crates that comprise the TACO toolsuite. You can find the source code for all of them in the crates directory.

Threshold Automaton Representations¶

These crates define different representations of threshold automata at different levels of abstraction, which can be used as inputs to model checkers.

taco-interval-ta: This library crate implements the interval abstraction of a threshold automaton. It contains a threshold automaton type that uses sets of (symbolic) intervals as guards.
taco-threshold-automaton: This crate defines the types:
- GeneralThresholdAutomaton, which is the most general form of a threshold automaton. For example, it allows comparisons between variables or guards in non-linear arithmetic. This type is designed to be easily parsable from a specification file, while providing some basic validation (by using the GeneralThresholdAutomatonBuilder).
- LIAThresholdAutomaton: A threshold automaton that is guaranteed to have only guards using integer linear arithmetic.

Model Checker Crates¶

Model checkers and specifications must implement the interfaces defined in the

taco-model-checker crate. This library crate defines the common interface for model checkers, as well as some useful preprocessing tools that can apply useful transformations or simplifications to threshold automata.

TACO already implements 3 algorithms, which are split into their own separate crates:

taco-acs-model-checker: Contains the implementation of the ‘ACS’ model checker.
taco-smt-model-checker: Contains the implementation of the ‘SMT’ model checker.
taco-zcs-model-checker: Contains the implementation of the ‘ZCS’ model checker.

Backend and Utility Crates¶

taco-bdd : This library crate implements a common interface to interact with BDD libraries. Currently it supports OxiDD and CUDD.
taco-cli: The binary crate containing the code of the TACO Command Line Interface.
taco-display-utils: A small library crate for common helper methods for nicely displaying types.
taco-parser: An interface definition of parsers that can be used to parse a threshold automaton from different formats. This crate already contains a parser for .ta and .eta files that has been introduced by ByMC here.
taco-smt-encoder: This library crate implements the configuration and setup of connections to SMT solvers. Additionally, it defines SMT encodings of types of the threshold-automaton crate and provides structures to encode constraints on configurations and paths.

Development Setup¶

Build TACO Executable¶

To build TACO you need the Rust tool chain to be installed. You can find instructions for the installation on the official installation website.

Once you have Rust and Rust’s package manager installed, you can build TACO by executing:

# Build TACO
cargo build
# or: build taco in release mode (executable can be found under `./target/release`)
cargo build --release

Executing this command will build the taco-cli executable which you can find in the directory ./target/debug.

While cargo will take care of installing all packages that are required to build TACO, to use TACO, at least one supported SMT solver must be installed. Please note that to execute the unit and integration tests, you will need to have Z3 and/or CVC5 installed. You can find installation instructions for supported SMT solvers here.

For installation instructions and additional components you might want to install, you can refer to Prerequisites.

Executing Tests & Code Coverage¶

You can execute all tests in TACO by using

cargo test --all-targets --all-features

If you want to obtain a code coverage report locally, you will need to have

llvm-tools, and
grcov installed

We have automated the installation and report generation in the coverage-report.sh script, which you can execute using

./scripts/coverage-report.sh

Note: Integration Tests and Benchmark Files¶

This repo does contain integration tests that will automatically test TACO’s components against subsets of the benchmark files that are stored under benchmarks/TACO and end with .ta or .eta. The purpose of these tests is to ensure that our tool can cope with all the benchmarks we/others have come up with.

When adding benchmarks, be careful, as they might impact the integration tests and subsequently CI pipelines. If you want benchmark files to be excluded from these tests, you can for example add the ending *.ta-ignore.

Building the Developer Documentation¶

TACO uses the standard Rust Doc comment and adds this page as a custom landing page. To build the developer documentation you can use the generate-dev-docs.sh script by executing:

./scripts/generate-dev-docs.sh

Or, you can also use the built-in cargo command:

cargo doc --open

However, this will not include the landing page of the documentation.

Displaying & Editing the User Documentation¶

The user documentation files for TACO can be found in the /docs. We use MyST Markdown for the TACO documentation.

To install MyST please refer to Installation Guide on the MyST website

Once MyST is installed, the documentation can be served by executing

# Start MyST in the `./docs` directory
cd ./docs && myst start

Debugging¶

TACO uses the Rust log crate for logging.

You can enable debug output in TACO by using the --debug flag. If you want even more detailed output, you can set the log level to trace, for example, by setting the RUST_LOG environment variable using:

export RUST_LOG="trace"

BDD Libraries¶

Building CUDD from Sources¶

Support for the CUDD library is added via the cudd_sys package.

If you are having issues with building CUDD (though they should be fixed in 1.1.0), you can try building CUDD from sources. This will require:

a C-compiler
autoconf
automake
libtool

to be installed.

On Debian / Ubuntu you can use

sudo apt-get install build-essential autoconf automake libtool

or under MacOS with homebrew using:

brew install autoconf automake libtool

to install the relevant build dependencies.

Debugging BDDs¶

OxiDD and CUDD both support dumping the BDD into a file in DOT Format. This feature can be enabled by compiling with the visualize feature enabled.

Adding Support for BDD Libraries¶

To add support for a new BDD library, implement the traits BDDManager and BDD for the library. The trait definitions can be found under model_checker > bdd.rs.

Contributing¶

In general, we tried to design TACO as modular as possible. You can reuse the whole model checker or only the components you need. We encourage you to write your own tools based on TACO.

If you have any questions or are facing issues with TACO, feel free to open an issue.
